1. Initial use and maintenance of fixed beam CNC gantry milling machine:

1. External maintenance Maintain the inner and outer surfaces of the machine tool. When changing products for processing, clean the work surface as appropriate, and check and trim burrs at any time.

2. Keep the spindle and tool magazine clean. Check the tool magazine when starting up, and the spindle needs to run at low speed for 10 minutes before working.

3. The knife handle and knife cover are neatly placed and rust-proof. Check that there should be no looseness or burrs on the screws.

4. The appearance of the computer should be kept clean and dust-free. Clean up junk files and organize folders at any time. The file naming needs to include (name, version, time, operator) and other information.

5. The electric control box should be kept clean and dust-free.

6. Lubricating oil Check the oil amount in the oil pool, and require the lubricating mechanism to have good performance, safety and reliability.

7. The coolant of fixed beam CNC gantry milling machine eliminates leakage and blockage.

8. The air duct and air gun are kept unblocked, and there is no air leakage.

9. The toolbox and table are kept clean inside and outside, neatly placed, and the workpiece is rust-proof.

10. Shelves should be kept clean, tidy and rust-proof.

Second, the first-level maintenance of the fixed beam CNC gantry milling machine after one week of use:

The fixed beam CNC gantry milling machine runs for one week, and the maintenance is carried out on the weekends every week, and the night shift team is rotated. Time about 1 hour. First cut off the power supply, and then carry out maintenance work.

1. External maintenance: Clean the inner and outer surfaces of the machine tool, keep the inside and outside clean, without rust and yellow robes. Clean the work surface, check and trim burrs. Apply an oil layer to protect.

2. Spindle and tool magazine Clean the tool magazine, and the tool holder needs to be removed from the spindle and put in another place to keep the spindle free. Use a clean soft cloth to clean the inside and outside of the spindle, keep it dust-free, and apply an oil layer to the inside of the spindle for protection. 3. Clean the knife handle and knife cover to ensure that the accessories are clean, neatly placed and rust-proof. Check that there should be no looseness or burrs on the screws.

4. Clean all parts of the computer, tie the wires neatly, and keep it dust-free. Antivirus

5. The electric control box of the fixed beam CNC gantry milling machine is cleaned. Keep dust-free, rust-free, oil-free, yellow robe free

6. Lubricating oil Check the oil amount in the oil pool, and require the lubricating mechanism to have good performance, safety and reliability.

7. Coolant cleaning to eliminate leakage and blockage.

8. Remove dust and oil from toolboxes and tables. So that the inside and outside are clean, neatly placed, and the workpiece is rust-proof.

9. Remove dust and oil from the shelves. Clean, tidy and rust-proof.

3. Secondary maintenance of fixed beam CNC gantry milling machine after one month of use:

The fixed beam CNC gantry milling machine runs for one month, and the second-level maintenance is carried out on the shift weekend at the end of the month. The time is about 1.5 hours. First cut off the power supply, and then carry out maintenance work

1. External maintenance: Clean the outer surface of the machine tool and the casings on the top of the machine tool. Keep the inside and outside clean, free of rust and yellow robes. Clean the work surface, check and trim burrs. Apply an oil layer to protect.

2. The spindle and tool magazine of the fixed beam CNC gantry milling machine should be cleaned and the tool magazine should be removed from the spindle to keep the spindle free. Use a clean soft cloth to clean the inside and outside of the spindle, keep it dust-free, and apply an oil layer to the inside of the spindle for protection.

3. Remove the guide rail protection from the guide rail, clean the accumulation at the guide rail, and apply an oil layer for protection. Check the limiter, requiring good performance, safety and reliability.

4. The knife handle and knife cover should be cleaned to ensure that the accessories are clean, neatly placed and rust-proof. Check that there should be no looseness or burrs on the screws.

5. Clean all parts of the computer, tie the wires neatly, and keep it dust-free. Update antivirus software.

6. The electric control box of the fixed beam CNC gantry milling machine is cleaned. Keep it dust-free, rust-free, oil-free, yellow robe free. After cleaning [ ] the fan filter.

7. Lubricating oil Check the oil amount in the oil pool, and require the lubrication mechanism to have good performance, safety and reliability.

8. Coolant cleaning eliminates leakage and blockage.

9. Remove dust and oil from toolboxes and tables. So that the inside and outside are clean, neatly placed, and the workpiece is rust-proof.

10. Remove dust and oil from the shelves. Clean, tidy and rust-proof.

The fixed beam CNC gantry milling machine and CNC gantry machining center completely replace the coolant every three months, and the cooling pump filter, cooling tank, water pipe and water valve must be cleaned. Eliminate leaks and blockages.
